[Pre-Order] MKC75 PCB Gasket Mount Keyboard Kit - Tri-mode Version Case (PVD Weight)

$182.00

Case Color
Description

Pre-order Bonus: A Super Cute Deskmat

Promotion Period: August 5th - August 10th (Beijing time)

Other Optional Extras:

AccessoriesBrass PVD Rotary Knob and LED Light Sign

Please add to cart with your keyboard, we don't combine any GB orders.

MKC75 Specifications
  • Typing angle: 7°
  • Front height: 18.5 mm
  • Material: Full CNC 6063 aluminum
  • Dimension: 320*134.4*33mm
  • Three-in-one Structure: TOP Mount / Plate Gasket Mount / PCB Gasket Mount
  • QMK/VIA Supported(wired)
  • Support PCB stabilizers
  • Unbuilt Weight ↓
  • With PVD WEIGHT: 1.693kg
  • With Alu WEIGHT: 1.425kg
  • Built Weight ↓
  • With PVD WEIGHT: 1.86kg
  • With Alu WEIGHT: 1.592kg
      What you can customize for MKC75?
      Case Colors Options:
      • 4 E-coat Case: E-white, Milky White, Pink, Lilac
      • 6 Anodized Case: Orange, Black, Brown, Grey, Silver, Green
      • 7 Color Combose Case: E-White&Black, Orange&Black, Grey&Black, Silver&Black, Wine Red&Black, Deep Blue&Black, Green&Black
      Weight Options:

      Designs:

      • Blank Weight (Default)
      • Cursive Text Weight (Add-on only)

      Colors:

        • 4 Alu Weight: Gold/Silver/Black/Rose Gold
        • 6 PVD SS Weight: Gold/Silver/Black/Blue/Rose Gold/Chroma
        PCB Options:
        • Wired Flex Cut Hotswap PCB( 1.2mm, Multi Layout , 7u split spacebar, No Per-key RGB, support QMK and VIA )
        • Wired Non-Flex Cut Hotswap PCB(1.6mm, Multi Layout, 7u split spacebar, No Per-key RGB, support QMK and VIA )
        • Wired Solder PCB(1.6mm, Non-Flex Cut, Multi Layout, 7u split spacebar, No Per-key RGB, support QMK and VIA )
        • Tri-mode ANSI+ISO Hotswap PCB (1.2mm, Non-Flex Cut, No Per-key RGB, support Mykeyclub Software)
        • Wired Per-Key RGB Hotswap PCB (Add-on only, 1.6mm, Non-Flex Cut, ANSI Layout, support QMK and VIA )
        Noted: The Tri-mode technical support is provided by IRISLab. Appreciate their support and help.
        Plate Options:
        • Plateless
        • Flex Cut Plates: FR4, ALU, Brass (Brass Plate Add-on only)
        • Non-flex Cut Plates: PC, POM
        • Alu and FR4 Half-plate (Both Add-on only)
        Noted: We highly recommend using a PC/ POM/FR4 plate for Tri-mode PCB because the Brass and ALU plate will have a little affection for connectivity.
        What's Included in MKC75?
        • Full CNC Aluminum Top case *1
        • Full CNC Aluminum Bottom case *1
        • Weight(Anodized Alu Weight or Stainless steel PVD Weight) *1
        • Internal Alu Weight (Only for the Tri-mode Version Case) *1
        • PCB *1
        • Plateless or Plate *1
        • IXPE Foam *1
        • Poron Case Foam *1
        • Poron Plate Foam *1
        • Type-C Daughterboard with JST Cable *1
        • PCB GAS Silicone Column *12
        • Plate GAS Silicone Sock *18
        • Top mount screw and spacer *12
        • PCB stabilizers o-ring *12
        • Footpad *6
        • Poron case strip *6
        • 1.6mm hex key *1
        Gift(will not send make-up or replacements)
        • 1 Pack of Extra Screw ↓
        • M2x3mm cylindrical head screw *2
        • M2x8mm cylindrical head screw *2
        • M3x12mm countersunk screw *2
        • M3x6mm countersunk screw *2
        • 2200mha battery (Only for the Tri-mode Version Case) *2
        • Silicone pad of battery compartment (Only for the Tri-mode Version Case) *2

        Group Buy or Pre-order Disclaimer

        1. The renders only provide an idea of what the final product will look like. The physical product may have some differences. Please also refer to the prototype's photos as a reference before purchasing.

        2. Estimates of time are our best guesses, they're not 100% guaranteed. Delays and setbacks may occur.

        3. DO NOT PURCHASE if you disagree with the terms and conditions.

        4. GB or Pre-order items will not have order combinations. Please place only one order.

        5. There will be a 4.4% fee on order cancellations and refunds after placing an order.

        6. Your payment method will be charged once you place the order. There are no change orders, refunds, or cancellations after the group buy or pre-order ends.

        7. Please complete the inspection below within three days after receiving the package. If you find any issues, kindly take some photos to show and contact our customer service team for further assistance.
        - Exterior Packaging Inspection: Please carefully examine the external packaging of the parcel for any signs of damage, such as noticeable tears or rips.
        - Item Quantity Verification: Kindly verify that the quantity of items within the package matches the details on the order.
        - Product Exterior Check: Please thoroughly inspect the products for defects and damages.

        Quality Disclaimer

        1. Each kit comes with fragile labels. Please check the appearance thoroughly before building. If you see any noticeable flaws/scratches on the external surfaces, please take a photo and contact us immediately. We’ll not be responsible for any flaws/scratches found after building.

        2. Due to the nature of the PVD coat, there may be minor, unavoidable dust points/micro scratches on the mirror finish of the PVD weight. The small dust points/micro scratches are only visible at just the right angle of the lighting.

        3. Chroma andGradient PVD Mirror Stainless steel weight has random nature. Each weight may have some slight differences.

        4. CNC marks and imperfections inside the keyboard case or dents on the subject are not visible when the keyboard is fully built. These are normal and within our quality acceptance.

        5. On all other surfaces and edges, blemishes under 2mm are approved.

        6. The bottom of the Solid Aluminum Wrist Rest is defined as a B-level surface because the bottom side is the hanger side during the anodized process. The QC standard for B-level cover: blemishes under 1cm are approved on the surfaces and edges. Three or fewer fine trachoma, dust spots, etc., are within our quality acceptance (The diameter is under0.5mm). Color uniformity is a normal phenomenon around the process hole, but it is guaranteed that it will not be visible after installation.

        7. Other than the case itself, all parts with cosmetic imperfections will not be replaced unless the function is damaged for usage.

        8. Warranty only applicable for the first owner who purchased on our website or at our collaborative shops, with proof of purchase such as order number and confirmation.

        9. Our warranty covers the PCB for one year of use or if dead on arrival without any modification.

        10. Broken parts due to any human error will void your warranty. Including below list but not only

        • - Mill-maxing PCB
        • - Tape modding PCB
        • - Hotswap Sockets that are pushed out of the PCB solder pads
        • - Did not follow the steps to flash PCB and caused no function

         11. Gifts will not ship out replacements or issue a partial refund.

        Shipping

        We aim to offer you the best shipping options, no matter where you live. We deliver to hundreds of customers worldwide every day and strive to provide you with services of the highest level.

        For the Group Buy product: Please pay attention to the project update.

        For the in-stock item: The estimated order delivery time is be divided into two parts:
        Processing time: 2-5 Days
        Shipping time: 7~30 Days

        The shipping estimate is only the time of travel, which is subject to delay due to covid.

        Shipping methods: Epacket/DHL/UPS/FedEx/USPS/Other economic shipping Shipping fee: Depends on weight and shipping method specified and selected by customers.

        Duties and import taxes:All costs associated with international shipping such as customs duties and import taxes are the responsibility of the customer.

        Shipping address: we do not accept any third-party logistics warehouse, otherwise the resulting return of goods, detention of goods, destruction and other related costs will be paid by the customer.

        Once departed, couriers will be liable for the delivery. In case of a package is lost after delivery, Mykeyclub is not responsible. However, we will assist during the claiming process in case of failed delivery.

        If you have any questions about your order delivery, please email service@mykeyclub.com

        MKC75 Feature

        - Compact 75% layout.
        - Supports Alu Internal Weight.
        - Multiple configurations available.
        - Supports Caps Lock Indicator Light.
        - Supports tri-mode PCB(Wired, Bluetooth and 2.4ghz).
        - 2 x 2200mha large battery capacity.
        - 100% processed using CNC machining with 6063 aluminum case.
        - Supports Plate, Half Plate and Plateless Build.
        - Three-in-one structural design( Top Mount, Plate Gasket Mount and PCB Gasket Mount ).
        - Supports Rotary Knobs and LED Light Signs.
        - Wired versions are also compatible with JRIS75 Rotary Knob, Badge, and LED Light Sign.

        THREE-IN-ONE STRUCTURE

        We have adopted a three-in-one structural design for the internal structure, which can support regular positioning plate gaskets, PCB gaskets, and the long-disappeared TOP Mount structure. Thanks to the consistent frame of the compact 75% layout, we can make the three structures perfectly compatible.

        THREE-IN-ONE STRUCTURE
        Rating of 1 means .
        Rating of 4 means .
        The rating of this product for "" is 3.

        TOP Mount

        THREE-IN-ONE STRUCTURE
        Rating of 1 means .
        Rating of 4 means .
        The rating of this product for "" is 2.

        PCB Gasket Mount

        THREE-IN-ONE STRUCTURE
        Rating of 1 means .
        Rating of 4 means .
        The rating of this product for "" is 1.

        Plate Gasket Mount

        THREE-IN-ONE STRUCTURE
        Rating of 1 means .
        Rating of 4 means .
        The rating of this product for "" is 3.

        TOP Mount

        Rating of 1 means .
        Rating of 4 means .
        The rating of this product for "" is 2.

        PCB Gasket Mount

        Rating of 1 means .
        Rating of 4 means .
        The rating of this product for "" is 1.

        Plate Gasket Mount

        Support Rotary Knob & Light Sign

        Note: The Rotary Knob and Light Sign have a separate daughterboard. And please note that the wired and wireless versions of the knob are not compatible.

        Rotary Knob

        Light Sign

        ---MKC75---

        What can you customize for MKC75?

        CASE OPTIONS

        • 4 E-coat case:E-white, Milky White, Pink, Lilac
        • 6 Anodized Case: Orange, Black, Brown, Grey, Silver, Green
        • 7 color combose case:E-White&Black, Orange&Black, Grey&Black, Silver&Black, Wine Red&Black, Deep Blue&Black, Green&Black

        WEIGHT OPTIONS

        Designs

        • Blank Weight (Default)
        • Cursive Text Weight (Add-on only)

        Colors

        • 4 Alu Weight: Gold/Silver/Rose Gold/Black
        • 6 PVD SS Weight: Gold/Silver/Black/Blue/Rose Gold/Chroma

        PCB OPTIONS

        • Wired Solder PCB(1.6mm, Non-Flex Cut, Multi Layout, 7u split spacebar, No Per-key RGB, support QMK and VIA )
        • Wired Flex Cut Hotswap PCB( 1.2mm, Multi Layout , 7u split spacebar, No Per-key RGB, support QMK and VIA )
        • Wired Non-Flex Cut Hotswap PCB(1.6mm, Multi Layout, 7u split spacebar, No Per-key RGB, support QMK and VIA )
        • Wired Per-Key RGB Hotswap PCB

        Add-on only, 1.6mm, Non-Flex Cut, ANSI Layout, support QMK and VIA )

        • Tri-mode ANSI+ISO Hotswap PCB

        (1.2mm, Non-Flex Cut, No Per-key RGB, support Mykeyclub Software)

        PLATE OPTIONS

        • Flex Cut Plates: FR4, ALU, Brass (Brass Plate Add-on only)
        • Non-flex Cut Plates: PC, POM
        • Alu and FR4 Half-plate (Both Add-ons only)
        • Plateless

        Noted: We highly recommend using a PC/ POM/FR4 plate for Tri-mode PCB, because the Brass and ALU plate will have a little affection for connectivity.

        ---MKC75---

        Specifications

        Typing angle: 7°
        Front height: 18.5 mm
        Material: Full CNC 6063 aluminum
        Dimension: 320*134.4*33mm
        Three-in-one Structure: TOP Mount / Plate Gasket Mount / PCB Gasket Mount
        QMK/VIA Supported(wired)
        Support PCB stabilizers
        Unbuilt Weight
        With PVD WEIGHT: 1.693kg
        With Alu WEIGHT: 1.425kg
        Built Weight
        With PVD WEIGHT: 1.86kg
        With Alu WEIGHT: 1.592kg

        ---MKC75---

        What's in package?

        Standard
        • Full CNC Aluminum Top case *1
        • Full CNC Aluminum Bottom case*1
        • Weight (Anodized Alu Weight or Stainless steel PVD Weight) *1
        • Internal Alu Weight (Only for the Tri-mode Version Case) *1
        • Plateless or Plate *1
        • PCB *1
        • IXPE Foam *1
        • Poron Case Foam *1
        • Poron Plate Foam *1
        • Type-C Daughterboard with JST Cable *1
        • PCB GAS Silicone Column *12
        • Plate GAS Silicone Sock *18
        • Top mount screw and spacer *12
        • PCB stabilizers o-ring *12
        • Footpad *6
        • Poron case strip *6
        • 1.5mm hex key *1
        Gift (will not send make-up or replacements)
        • 1 Pack of Extra Screw
        • M2x3mm cylindrical head screw *2
        • M2x8mm cylindrical head screw *2
        • M3x12mm countersunk screw *2
        • M3x6mm countersunk screw *2
        • 2200mha battery (Only for the Tri-mode Version Case) *2
        • Silicone pad of battery compartment (Only for the Tri-mode Version Case) *2
